| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,634 pcs
|
1634 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Material | |
| Connector | |
| Connector Type | |
| Contact Finish | |
| Features | |
| Flat Flex Type | |
| Height Above Board | |
| Housing Material | |
| Lead Spacing | |
| Locking Feature | |
| Mounting Type | |
| Number of Positions | |
| Pitch | |
| Tape & Reel | |
| Termination |
The TE Connectivity 84501-1 is a 12-position FFC (Flat Flexible Cable) connector designed for through hole mounting. It features a 2.54mm (0.100 inch) pitch and vertical, 1-sided contact configuration. The connector incorporates a zero insertion force (ZIF) mechanism with a slide lock actuator for secure cable retention without requiring excessive force.
The housing and actuator are made of thermoplastic material, providing durability and insulation. The contacts are tin-plated for reliable electrical connection. The connector has a height above board of 7.87mm (0.310 inches). It is designed for solder termination.
This connector is suitable for applications requiring reliable interconnection of flat flexible cables to PCBs. The through hole mounting ensures robust mechanical attachment. The ZIF design simplifies assembly and reduces wear on the cable contacts.
Compliance data indicates RoHS3 compliance, MSL 1 (unlimited), and REACH unaffected, though these should be verified from official documentation. Cross-references include Digi-Key part numbers A109513-ND and 2266-84501-1-ND.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.42 | $1.42 |
| 10+ | $1.36 | $1.36 |
| 26+ | $1.35 | $1.35 |
| 507+ | $1.19 | $1.19 |
| 1,001+ | $1.17 | $1.17 |
| 2,509+ | $1.16 | $1.16 |
| 5,005+ | $0.84 | $0.84 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
12 positions.
2.54mm (0.100 inches).
Through hole.
FFC connector with contacts, vertical, 1 sided.
Yes, it has a slide lock.
Tin.
RoHS3 Compliant.
