| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Illumination | |
| Mounting Type | |
| Number of Poles | |
| Operating Temperature | |
| Storage Temperature | |
| Tape & Reel | |
| Voltage Rating |
This E-T-A 8340-G221-N1H2-A4H211-6A is a two-pole magnetic circuit breaker with hydraulic delay, suitable for panel mounting. It offers a current rating of 6A and a voltage rating of 240V AC, with approvals from CSA, IEC, and UL.
The breaker is designed with a push-pull plunger actuator and a threadneck panel mounting style. It operates within an ambient temperature range of -40 to 85°C. The device meets IEC 60934 standards for interrupting capacity, rated at 6 x IN for AC and 4 x IN for DC.
Typical applications for this circuit breaker include control equipment, communications systems, and power semiconductors. Its robust design ensures reliable protection in various industrial and electronic systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 6A.
The voltage rating is 415V AC, 240V AC at 50/60 Hz, and 80V DC.
This circuit breaker has two poles.
It supports panel mounting.
The operating temperature range is -40 to 85 °C.
