| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Style | |
| Termination |
The Preci-Dip 833-87-040-10-001101 is a 40 position, 2.00mm pitch, through hole socket connector designed for board-to-board applications. It features a black UL94 V-0 rated insulator and tin plated female socket contacts with a flash thickness. The connector has a push-pull fastening type and is loaded with all 40 positions in a 2-row configuration.
This socket connector is rated for a current of 3A and operates over a temperature range of -55°C to 125°C. The insulation height is 4.20mm and the contact length is 3.18mm. The connector uses solder termination for through hole mounting.
The 833-87-040-10-001101 is suitable for use in various electronic assemblies requiring a reliable board-to-board connection. The 2.00mm pitch allows for compact designs while maintaining adequate spacing for signal integrity.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.33 | $6.33 |
| 10+ | $5.73 | $5.73 |
| 25+ | $5.41 | $5.41 |
| 50+ | $5.28 | $5.28 |
| 100+ | $5.02 | $5.02 |
| 200+ | $3.22 | $3.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.00mm (0.079 inches).
It has 40 positions, all loaded, in 2 rows.
The current rating is 3A.
The operating temperature range is -55°C to 125°C.
It is a through hole mounting connector with solder termination.
The contact finish is tin (flash thickness).
The insulation material has a UL94 V-0 flammability rating.
