831022731 The 831022731 is a 100 MHz XO (Standard) crystal oscillator from Würth Elektronik with HCMOS output. It operates at 3.3V with ±50 ppm frequency stability over -40°C to 85°C.
Mfr Part #:

831022731

Available from 1 distributors
Mfr Name: Würth Elektronik
Würth Elektronik
The 831022731 is a 100 MHz XO (Standard) crystal oscillator from Würth Elektronik with HCMOS output. It operates at 3.3V with ±50 ppm frequency stability over -40°C to 85°C.
✓ Total Stock: 95 pcs
$ Price Range: $2.01 - $2.99

831022731 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Akira Global ✓
Non-Authorised Inventory information
95 pcs
On Request
95 pcs On Request 1 On Request On Request 2213 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

831022731 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Base Resonator
Current
Duty Cycle
Frequency
Frequency Stability
Function
Height
Length
Mounting Type
Operating Temperature
Output
SVHC Present
Storage Temperature
Tape & Reel
Termination Finish
Type
Voltage
Width
View Similar Products (0)

831022731 Description

Short technical summary and product information.

The Würth Elektronik 831022731 is a 100 MHz crystal oscillator (XO) in a standard 7.2 x 5.2 mm ceramic package with a seam-sealed metal lid. It features HCMOS output logic with a 15 pF drive capability, 45/55% duty cycle, and typical rise/fall time of 4.0 ns. The oscillator operates from a 3.3V supply voltage, drawing 40 mA typical current, and offers a standby (power down) function via pin 1.



Frequency stability is ±50 ppm over the extended industrial temperature range of -40°C to 85°C. The device exhibits typical phase noise performance of -149 dBc/Hz at 10 kHz offset and RMS phase jitter of 52 fs (12 kHz to 20 MHz). Ageing is limited to ±3 ppm per year maximum.



Designed for surface mount assembly, the 831022731 comes in a 4-SMD, no lead package and is supplied in tape and reel packaging (1000 units per reel). The terminations are nickel-gold (NiAu) finish, compatible with RoHS reflow soldering at 260°C for 10 seconds. Environmental testing includes shock per MIL-STD-202, Method 213, Condition E and vibration per MIL-STD-883, Method 2007, Condition A.

831022731 Quick Information

Product Type: Oscillator
Series: CFPS-73
Canonical Name: Würth Elektronik 831022731 Crystal Oscillator XO (Standard) 100 MHz HCMOS
Subcategory: Standard Oscillators

831022731 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

831022731 Estimated Pricing

Qty Low High
1+ $2.99 $2.99
10+ $2.89 $2.89
50+ $2.77 $2.77
100+ $2.43 $2.43
500+ $2.36 $2.36
1,000+ $2.01 $2.01

Estimated market price range - modelled values for guidance only, not live distributor offers.

831022731 Features

  • 100 MHz HCMOS output oscillator.
  • 3.3V supply with ±50 ppm stability.
  • Operating temperature range -40°C to 85°C.
  • Standby power down function with 10 µA max current.
  • 7.2 x 5.2 mm SMD ceramic package.

831022731 Applications

  • Provides clock signal for microprocessors and FPGAs.
  • Suitable for Ethernet and data communication interfaces.
  • Operates reliably in harsh industrial environments.
  • Used in test and measurement equipment.

831022731 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage of the 831022731?

3.3V ±10%.

What is the package type and dimensions?

4-SMD, No Lead, 7.2 mm x 5.2 mm x 1.4 mm.

What is the operating temperature range?

-40°C to 85°C.

Is the 831022731 RoHS compliant?

Yes, RoHS3 compliant. Also REACH unaffected.

What is the frequency of the oscillator?

100.0000 MHz.

What output logic does it support?

HCMOS.

Does it have a standby function?

Yes, standby (power down) function via pin 1.
