830208331709

The 830208331709 is a 100 MHz LVDS crystal oscillator (XO) from Würth Elektronik, part of the WE-SPXO series. It provides a standard LVDS output with a typical differential output voltage of 0.33V and offset voltage of 1.25V. The oscillator features a frequency stability of ±50ppm over the full operating temperature range of -40°C to 105°C. Supply voltage is 3.3V with a current draw of 50mA typical. The device includes a standby (power down) function, controlled by logic level on pad 1, with a standby current of 10µA max. Rise and fall times are 0.5ns max (20-80%). The phase jitter is 1ps rms max (12kHz to 20MHz). The package is a 6-SMD, no lead ceramic package measuring 3.20mm x 2.50mm x 1.10mm, ideal for surface mount assembly. This oscillator is suitable for high-speed digital applications requiring low jitter and LVDS interface, such as networking, telecommunications, and data communication systems. The operating temperature range of -40°C to 105°C makes it suitable for industrial environments. The device is RoHS compliant and has MSL 1 (unlimited).
