Mfr Part #:

826925-3

This is a 6-position, 2.54mm pitch breakaway header from TE Connectivity. It features through-hole mounting, tin-plated copper alloy contacts, and a green PBT insulator rated UL94 V-0.

✓ Total Stock: 7,200 pcs

$ Price Range: $0.37 - $0.77

826925-3 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
AA2DE ✓ Non-Authorised Inventory information	7,200 pcs On Request	7200 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

826925-3 Description

Short technical summary and product information.

The TE Connectivity 826925-3 is a 6-position, 2.54mm pitch breakaway header designed for board-to-board or cable applications. This unshrouded male pin connector features a dual-row configuration with all positions loaded, providing a reliable interconnection solution. The through-hole mounting style with solder termination ensures secure attachment to PCBs.

The header is constructed with copper alloy contacts plated with 78.7µin of tin, offering good conductivity and corrosion resistance. The overall contact length is 0.500" (12.70mm), with a contact length of 6.70mm. The green PBT insulator meets UL94 V-0 flammability rating, and the operating temperature range spans -65°C to 105°C. The current rating is 5A per contact.

This component is RoHS3 compliant, REACH unaffected, and has an MSL of 1 (unlimited). It is a breakaway style, allowing for easy customization of pin count if needed. The push-pull fastening type ensures simple insertion and extraction.

826925-3 Quick Information

Product Type: Header, Male Pin

Series: AMPMODU Mod II

Canonical Name: 826925-3 - 6 Position 2.54mm Header, Breakaway

Subcategory: Breakaway Header

826925-3 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Lead Free: Yes

826925-3 Estimated Pricing

Qty	Low	High
1+	$0.77	$0.77
10+	$0.67	$0.67
25+	$0.55	$0.55
100+	$0.50	$0.50
250+	$0.45	$0.45
800+	$0.41	$0.41
2,400+	$0.40	$0.40
5,600+	$0.39	$0.39
10,400+	$0.37	$0.37

Estimated market price range - modelled values for guidance only, not live distributor offers.

826925-3 Features

6 positions in 2 rows.
2.54mm pitch for compact designs.
Through-hole mounting for secure PCB attachment.
Rated for 5A current per contact.
Tin-plated copper alloy contacts.

826925-3 Applications

Board-to-board interconnection in industrial electronics.
Cable-to-header connections in consumer devices.
Used in prototype and production PCB assemblies.
Breakaway design allows custom pin count.

826925-3 FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does this header have?

6 positions.

What is the pitch of this connector?

2.54mm (0.100").

What is the current rating of this header?

5A per contact.

What is the mounting type of this header?

Through hole with solder termination.

What is the operating temperature range?

-65°C to 105°C.

What material is the insulator made of?

Polybutylene Terephthalate (PBT) with UL94 V-0 rating.

What is the contact finish?

Tin with 78.7µin thickness.

Category	Headers, Male Pins
Manufacturer Name	TE Connectivity
Connector Type	Header, Breakaway
Contact Finish	Tin
Contact Finish Thickness	78.7µin (2.00µm)
Contact Length	6.70mm (0.264")
Contact Material	Copper Alloy
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	5A
Fastening Type	Push-Pull
Insulation Color	Green
Insulation Height	2.79mm (0.110")
Insulation Material	Polybutylene Terephthalate (PBT)
Lead Spacing	2.54 mm
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	6
Number of Positions Loaded	All
Number of Rows	2
Operating Temperature	-65°C ~ 105°C
Overall Contact Length	0.500" (12.70mm)
Pitch	2.54mm (0.100")
Row Spacing	0.100" (2.54mm)
Shrouding	Unshrouded
Storage Temperature	-65°C ~ 105°C
Style	Board to Board or Cable
Tape & Reel	No
Termination	Solder
