| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
600 pcs
|
600 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The TE Connectivity 825440-5 is a 10-position, 2-row header connector with a 2.54mm pitch. It is designed for through-hole mounting and solder termination, making it suitable for board-to-board or cable applications. The connector features a push-pull fastening type and unshrouded design. The contacts are made of brass with a tin finish, and the insulator is made of green polybutylene terephthalate (PBT) with a UL94 V-0 flammability rating. The operating temperature range is -65°C to 105°C. This header is RoHS compliant and has an MSL of 1. It is commonly used in various electronic applications requiring reliable interconnection.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.52 | $1.52 |
| 10+ | $1.38 | $1.38 |
| 25+ | $1.30 | $1.30 |
| 100+ | $1.25 | $1.25 |
| 250+ | $1.17 | $1.17 |
| 400+ | $1.01 | $1.01 |
| 1,200+ | $0.99 | $0.99 |
| 2,800+ | $0.97 | $0.97 |
| 5,200+ | $0.92 | $0.92 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
10 positions.
2.54mm (0.100").
Through hole.
Brass contacts with tin finish.
-65°C to 105°C.
Unshrouded.
Push-pull.
