Mfr Part #:

813-SS-020-10-474101

Mfr Name: Preci-Dip

Spring piston connector with 20 positions, 2.54mm pitch, through hole mounting. Gold-plated brass contacts with 0.50µm finish.

✓ Total Stock: 10 pcs

$ Price Range: $16.07 - $16.75

813-SS-020-10-474101 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
ADI/AAR OEM Supply ✓ Non-Authorised Inventory information	10 pcs On Request	10 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

813-SS-020-10-474101 Description

Short technical summary and product information.

The 813-SS-020-10-474101 is a 20-position spring piston connector manufactured by Preci-Dip. It features a through-hole mounting style and a dual-row configuration with a 2.54mm pitch and row spacing. The contacts are made of brass with a gold plating of 0.50µm (19.7µin). This connector is part of the spring-loaded family of rectangular connectors, designed for applications requiring reliable contact under vibration or repeated mating cycles. The 2.54mm grid spacing is common for prototyping and standard PCB layouts. The housing and contacts are suitable for a range of industrial and electronic assemblies.

813-SS-020-10-474101 Quick Information

Product Type: Spring Piston Connector

Series: 813

Canonical Name: Spring Piston Connector, 20 Position, Through Hole, 2.54mm Pitch

Subcategory: Rectangular Connectors

813-SS-020-10-474101 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

813-SS-020-10-474101 Estimated Pricing

Qty	Low	High
70+	$16.75	$16.75
280+	$16.34	$16.34
560+	$16.07	$16.07

Estimated market price range - modelled values for guidance only, not live distributor offers.

813-SS-020-10-474101 Features

20-position spring piston connector.
Through hole mounting with 2.54mm pitch.
Gold-plated brass contacts for reliability.
Dual-row configuration with 2.54mm row spacing.
0.50µm gold contact finish thickness.

813-SS-020-10-474101 Applications

Suitable for board-to-board connections.
Used in testing and programming jigs.
Ideal for applications requiring vibration resistance.
Works with standard 2.54mm grid PCBs.

813-SS-020-10-474101 FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the 813-SS-020-10-474101 have?

20 positions.

What is the pitch of this connector?

2.54mm (0.100").

What is the mounting type?

Through hole.

What is the contact finish?

Gold with 0.50µm thickness.

How many rows does the connector have?

2 rows.

What is the row spacing?
