8124K Ebm-Papst 8124K is a 24VDC tubeaxial fan measuring 80mm x 80mm x 38mm. It delivers 35.0 CFM of airflow at 3450 RPM with a noise level of 39.0 dB(A).
Mfr Part #:

8124K

Available from 1 distributors
Mfr Name: Ebm-Papst
Ebm-Papst
Ebm-Papst 8124K is a 24VDC tubeaxial fan measuring 80mm x 80mm x 38mm. It delivers 35.0 CFM of airflow at 3450 RPM with a noise level of 39.0 dB(A).
Stock on Request

8124K Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
DYNACO PRODUCTS ✓
Non-Authorised Inventory information
On Request
On Request
On Request On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

8124K Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Air Flow
Automotive Grade
Bearing Type
Fan Type
Industrial Grade
Medical Grade
Military Grade
Noise
Operating Temperature
Power (Watts)
RPM
Termination
Voltage
Weight
Width
View Similar Products (0)

8124K Description

Short technical summary and product information.

The Ebm-Papst 8124K is a DC brushless tubeaxial fan designed for cooling applications. It operates at 24 VDC with a power consumption of 3 W. The fan delivers an airflow of 35.0 CFM (0.98 m³/min) at 3450 RPM, generating a noise level of 39.0 dB(A). It features a ball bearing system for reliable long-life operation. The fan has a square frame of 80mm x 80mm with a depth of 38mm and weighs 425.02 g. Termination is via 2 wire leads. The operating temperature range is -20°C to 70°C. The fan is RoHS3 compliant and has REACH unaffected status. Note: compliance data is unverified.

8124K Quick Information

Product Type: DC Brushless Axial Fan
Canonical Name: Ebm-Papst 8124K DC Axial Fan, 80x38mm, 24VDC, 35.0 CFM
Subcategory: Tubeaxial Fan

8124K Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

8124K Features

  • 24VDC operation with 3W power consumption.
  • Delivers 35.0 CFM airflow at 3450 RPM.
  • Ball bearing for extended service life.
  • 80mm x 80mm x 38mm frame size.
  • Noise level of 39.0 dB(A).

8124K Applications

  • Cooling of electronic components and enclosures.
  • Air circulation in industrial equipment.
  • Ventilation for telecommunications systems.
  • Heat dissipation in power supplies.

8124K FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage of the Ebm-Papst 8124K fan?

24 VDC.

What is the operating temperature range?

-20 to 70°C.

Is the 8124K fan RoHS compliant?

Yes, RoHS3 compliant (unverified).

What is the airflow of the 8124K fan?

35.0 CFM (0.98 m³/min).

What is the noise level?

39.0 dB(A).

What are the dimensions of the fan?

80mm x 80mm frame, 38mm depth.

What type of bearing does the fan use?

Ball bearing.
