| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
245 pcs
|
245 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The 3M 81100-650403 is a 100-position, 2-row rectangular header designed for board-to-cable/wire applications. It features a 1.27mm (0.050") pitch and 2.54mm (0.100") row spacing, making it suitable for high-density interconnect requirements. The header is through-hole mounted with solder termination, ensuring reliable mechanical and electrical connections.
The connector is shrouded on all four walls and includes latch lock/eject hooks for secure mating. It has a board lock feature for enhanced retention on the PCB. The contacts are male square pins made of copper alloy with a tin-lead finish (30.0µin / 0.76µm), providing good conductivity and solderability. The insulator is black liquid crystal polymer (LCP) with a UL94 V-0 flammability rating.
Electrical specifications include a current rating of 0.75A per contact. The operating temperature range is -55°C to +105°C, making it suitable for a wide range of environments. The header is designed for board-to-cable/wire connections, commonly used in industrial, telecommunications, and data processing equipment where reliable and compact interconnects are required.
| Qty | Low | High |
|---|---|---|
| 900+ | $16.56 | $16.56 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 1.27mm (0.050").
It has 100 positions arranged in 2 rows.
The current rating is 0.75A.
It is a through-hole mount with solder termination.
The operating temperature range is -55°C to +105°C.
