| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
50 pcs
|
50 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Style | |
| Termination | |
| Termination Style |
This is a 40-position female socket connector from Preci-Dip, part of the 803 series. It features a 2.54mm pitch and 2 rows, designed for board-to-board applications. The connector uses through hole mounting with solder termination. Contacts are tin-plated female sockets. Insulation is black with UL94 V-0 flammability rating. Current rating is 3A. Operating temperature range -55°C to 125°C. Fastening type is push-pull. Contact length 3.00mm, insulation height 7.00mm. All 40 positions are loaded. Suitable for various electronic interconnections requiring reliable socket connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $4.53 | $4.53 |
| 10+ | $3.85 | $3.85 |
| 270+ | $3.05 | $3.05 |
| 540+ | $3.04 | $3.04 |
| 1,080+ | $2.76 | $2.76 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
40 positions.
2.54mm (0.100 inches).
3A.
Through hole.
-55°C to 125°C.
