| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | 1616 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Bend Radius (Stationary Min. Installation Min.) | |
| Cable Type | |
| Cable Weight | |
| Conductor DC Resistance | |
| Conductor Material | |
| Conductor Strand | |
| Jacket Color | |
| Lead Style | |
| Length | |
| Max Pull Tension | |
| Medical Grade | |
| Overall Cable Diameter (Nominal) | |
| Prop 65 | |
| Putup Length | |
| Putup Type | |
| SVHC Present | |
| Wire Gauge |
The Belden 8020 000100 is a non-insulated bus bar wire designed for use in bus bar applications. It features a 20 AWG solid tinned copper conductor, providing reliable electrical conductivity with a nominal DC resistance of 10.2 Ohm per 1000 feet. The wire has an overall diameter of 0.032 inches (0.81 mm) and a minimum bend radius of 0.13 inches (3.3 mm) for both stationary and installation conditions. It can withstand a maximum pull tension of 12.4 lbs (5.62 kg) and weighs 3 lbs per 1000 feet. The wire is supplied on a 100 ft reel and is RoHS3 compliant, meeting EU Directive 2011/65/EU and amendment 2015/863/EU. It is also listed under California Proposition 65. This bus bar wire is suitable for applications requiring a solid, tinned copper conductor without insulation.
| Qty | Low | High |
|---|---|---|
| 1+ | $108.73 | $108.73 |
| 2+ | $102.25 | $102.25 |
| 5+ | $99.42 | $99.42 |
| 10+ | $94.99 | $94.99 |
| 25+ | $92.26 | $92.26 |
| 50+ | $87.61 | $87.61 |
| 100+ | $83.14 | $83.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
20 AWG solid tinned copper.
No, it is non-insulated (no jacket).
10.2 Ohm per 1000 feet.
100 feet.
Yes, it is RoHS3 compliant per EU Directive 2011/65/EU and amendment 2015/863/EU.
Minimum bend radius is 0.13 inches (3.3 mm) for both stationary and installation.
12.4 lbs (5.62 kg).
