| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
6,767 pcs
|
6767 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Clip Material | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Resistance | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Dielectric Strength | |
| Fastening Type | |
| Flammability | |
| Insertion Force | |
| Insulation Color | |
| Insulation Height | |
| Insulator Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mating Pin Diameter | |
| Mechanical Life | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Sleeve Material | |
| Style | |
| Termination | |
| Termination Style | |
| Withdrawal Force |
The Preci-Dip 801-87-005-10-001101 is a 5 position single row socket connector designed for board-to-board applications. It features a 2.54mm pitch and through hole solder termination.
The insulator is black glass filled polyester PCT-GF30-FR with a UL94 V-0 flammability rating. The sleeve is brass and the contact clip is beryllium copper (6 finger design). Contact finish is flash tin. The connector accommodates mating pin diameters of 0.70 to 0.90 mm. Electrical characteristics include a rated current of 3A, contact resistance max 10 mΩ, dielectric strength min 1000 Vrms, and an operating temperature range of -55°C to 125°C. Insertion and withdrawal forces are 1.2 N and 0.6 N typical, with a minimum mechanical life of 500 cycles. Packaging is bulk.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.84 | $0.84 |
| 10+ | $0.72 | $0.72 |
| 100+ | $0.61 | $0.61 |
| 500+ | $0.54 | $0.54 |
| 1,000+ | $0.52 | $0.52 |
| 2,600+ | $0.47 | $0.47 |
| 5,200+ | $0.45 | $0.45 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 5 positions in a single row.
The pitch is 2.54mm (0.100 inch).
The rated current is 3A.
Through hole with solder termination.
