800T-QB24R The Allen Bradley 800T-QB24R is a momentary contact, illuminated push button featuring a red lens, extended head without guard, and 24V AC/DC incandescent illumination.
Mfr Part #:

800T-QB24R

Available from 1 distributors
Mfr Name: Allen Bradley
Allen Bradley
The Allen Bradley 800T-QB24R is a momentary contact, illuminated push button featuring a red lens, extended head without guard, and 24V AC/DC incandescent illumination.
✓ Total Stock: 1 pcs
$ Price Range: $2.13

800T-QB24R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
1 pcs
On Request
1 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

800T-QB24R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Contact Type
Lens Color
Mounting Type
Storage Temperature
Tape & Reel
Type
Voltage
View Similar Products (0)

800T-QB24R Description

Short technical summary and product information.

The Allen Bradley 800T-QB24R is a momentary contact, illuminated push button designed for industrial applications. It features a 30.5mm size with an extended head and no guard, finished in red.



This push button operates at 24V AC/DC and utilizes incandescent illumination. The contact configuration includes one normally open (NO) and one normally closed (NC) contact block, providing versatile switching capabilities. The Type 4/13 rating indicates suitability for specific environmental conditions.



Assembly is factory-assembled, ensuring quality and reliability. This component is suitable for general-purpose applications where a momentary push-to-actuate function is required with visual indication.

800T-QB24R Quick Information

Product Type: Momentary Contact Push Button
Series: 800T
Canonical Name: Allen Bradley 800T-QB24R Momentary Contact Illuminated Push Button
Subcategory: Momentary Contact, Illuminated

800T-QB24R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

800T-QB24R Estimated Pricing

Qty Low High
1+ $2.13 $2.13

Estimated market price range - modelled values for guidance only, not live distributor offers.

800T-QB24R Features

  • Momentary contact push button operation.
  • 24V AC/DC incandescent illumination.
  • Includes 1 NO and 1 NC contact block.
  • Extended head, red lens, no guard.
  • Factory assembled for reliability.

800T-QB24R Applications

  • Used in industrial control panels.
  • Suitable for emergency stop buttons.
  • Ideal for machinery start/stop operations.
  • Applied in automation and safety systems.

800T-QB24R FAQs

7 frequently asked questions generated from this part’s specifications.
What is the voltage rating for the 800T-QB24R push button?

The 800T-QB24R push button has a voltage rating of 24V AC/DC.

What type of illumination does the 800T-QB24R use?

The 800T-QB24R uses incandescent illumination.

What is the contact configuration of the 800T-QB24R?

The 800T-QB24R features a 1 NO-1 NC contact block configuration.

What is the lens color on the 800T-QB24R push button?

The lens color on the 800T-QB24R push button is red.

What is the head type of the 800T-QB24R push button?

The 800T-QB24R push button has an extended head without a guard.

What is the RoHS status for the 800T-QB24R?

The 800T-QB24R is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the 800T-QB24R?

The Moisture Sensitivity Level (MSL) for the 800T-QB24R is 1 Unlimited.
