800-80-010-20-001101 10 position single row unshrouded male pin header from Preci-Dip with 2.54mm pitch, right angle through hole mounting, rated 3A at 150VDC.
Mfr Part #:

800-80-010-20-001101

Available from 1 distributors
Mfr Name: Preci-Dip
Preci-Dip
10 position single row unshrouded male pin header from Preci-Dip with 2.54mm pitch, right angle through hole mounting, rated 3A at 150VDC.
✓ Total Stock: 30 pcs
$ Price Range: $0.93 - $1.03

800-80-010-20-001101 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
30 pcs
On Request
30 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

800-80-010-20-001101 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Industrial Grade
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Medical Grade
Military Grade
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
SVHC Present
Shrouding
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

800-80-010-20-001101 Description

Short technical summary and product information.

The Preci-Dip 800-80-010-20-001101 is a 10 position single row unshrouded male pin header designed for board-to-board applications. It features a 2.54mm (0.100") pitch and right angle through hole mounting with solder termination. The header uses brass contacts with a tin finish and a circular contact shape, with a contact length of 4.95mm (0.195").



The insulator is molded from black polycyclohexylenedimethylene terephthalate (PCT) polyester, glass filled, with a UL94 V-0 flammability rating. The header is rated for 3A current and 150VDC voltage, with an operating temperature range of -55°C to 125°C. The push-pull fastening type ensures secure mating in unshrouded configurations.



This component is suitable for general purpose board-to-board interconnects where a compact, right-angle header is required. The unshrouded design allows for easy mating with standard female socket connectors.

800-80-010-20-001101 Quick Information

Product Type: Header, Male Pins
Series: 800
Canonical Name: 10 Position Single Row Male Pin Header, Unshrouded, Right Angle, Through Hole, 2.54mm Pitch
Subcategory: Unshrouded Male Pin Header

800-80-010-20-001101 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

800-80-010-20-001101 Estimated Pricing

Qty Low High
1,100+ $1.03 $1.03
2,200+ $0.97 $0.97
5,500+ $0.93 $0.93

Estimated market price range - modelled values for guidance only, not live distributor offers.

800-80-010-20-001101 Features

  • 10 position single row unshrouded header.
  • 2.54mm pitch with right angle mounting.
  • Tin plated brass circular contacts.
  • Rated 3A at 150VDC operation.
  • UL94 V-0 rated insulation material.

800-80-010-20-001101 Applications

  • Board-to-board interconnect applications.
  • General purpose signal and power connections.
  • Compact right-angle header designs.

800-80-010-20-001101 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the pitch of this header?

2.54mm (0.100")

How many positions does this header have?

10 positions, all loaded, in a single row.

What is the current rating?

3A

What is the voltage rating?

150VDC

What is the mounting type?

Through hole, right angle with solder termination.
