| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,000 pcs
|
2000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Dimensions | |
| Input Type | |
| Mounting Type | |
| Number of ADCs | |
| Number of Pins | |
| Operating Temperature | |
| Resolution | |
| Supply Voltage |
The Würth Elektronik MCP3208-BI/P is a high-performance analog-to-digital converter (ADC) from the MCP30/MCP32/MCP33 series. This device features 8 channels, providing an octal configuration for multiple input signals. It offers a 12-bit resolution, enabling precise conversion of analog signals to digital values.
The ADC operates with a sampling rate of up to 100kSPS, making it suitable for applications requiring moderate speed data acquisition. The digital interface is Serial Peripheral Interface (SPI), ensuring efficient communication with microcontrollers and other digital systems. A single supply voltage of 5V is required for operation.
Designed for through-hole mounting, the MCP3208-BI/P comes in a 16-pin PDIP package. It has an integral non-linearity of ±1 LSB, contributing to its accuracy. The operating temperature range spans from -40°C to 125°C, allowing for use in various environmental conditions. The dimensions of the package are 19.05 x 6.35 x 3.3mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resolution is 12 bits.
It has 8 analog input channels.
The sampling rate is 100 kSPS.
It uses a serial SPI interface.
The supply voltage is 5V (single supply).
The operating temperature range is -40°C to +125°C.
It is available in a 16-pin PDIP package with through-hole mounting.
