| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,750 pcs
|
5750 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,841 pcs
|
1841 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Fastening Type | |
| Housing Material | |
| Insulation Color | |
| Insulation Height | |
| Insulation Resistance | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| PCB Mount Retention | |
| Pitch | |
| Row Spacing | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Method | |
| Voltage Rating |
The TE Connectivity 8-215079-2 is a 12-position, 2-row receptacle connector with a 2.54mm pitch, part of the Micro-MaTch Industrial series. It is designed for board-to-board or wire-to-board connections and features a vertical, top-entry orientation. The connector uses through-hole mounting with kinked solder tails for secure PCB retention. Contacts are made of phosphor bronze with a tin plating, and the housing is red PBT GF (glass-filled) material. Electrical ratings include 1A per contact, 100VDC operating voltage, and 1000 MΩ insulation resistance. The operating temperature range is -40°C to 105°C, and the housing has a UL94 V-0 flammability rating. This connector is suitable for industrial and consumer electronics applications requiring reliable signal and low-power transmission.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.13 | $2.13 |
| 10+ | $1.81 | $1.81 |
| 25+ | $1.79 | $1.79 |
| 100+ | $1.54 | $1.54 |
| 250+ | $1.44 | $1.44 |
| 500+ | $1.33 | $1.33 |
| 1,000+ | $1.24 | $1.24 |
| 2,500+ | $1.16 | $1.16 |
| 5,000+ | $1.12 | $1.12 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
12 positions.
2.54mm (0.1 inch).
1A per contact.
100VDC.
Through hole.
-40°C to 105°C.
Yes, it is listed as RoHS3 compliant (unverified low confidence).
