| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
495 pcs
|
495 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
495 pcs
|
495 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| ESR (Equivalent Series Resistance) | |
| Frequency | |
| Frequency Stability | |
| Frequency Tolerance | |
| Height | |
| Length | |
| Load Capacitance | |
| Mounting Type | |
| Operating Mode | |
| Operating Temperature | |
| Tape & Reel | |
| Type | |
| Width |
The TXC Corporation 7B-12.000MAAJ-T is a 12 MHz fundamental mode quartz crystal designed for surface mount applications. It operates with a load capacitance of 18 pF and provides a frequency tolerance of ±30 ppm and frequency stability of ±30 ppm over the operating temperature range of -20°C to +70°C. The equivalent series resistance is 100 Ω.
This crystal is housed in a compact 4-SMD, no lead package measuring 5.00mm x 3.20mm with a height of 1.05mm. The surface mount design enables automated assembly and is suitable for high-density PCB layouts. The fundamental operating mode ensures reliable oscillation without overtone complications.
Typical applications include timing circuits in microcontrollers, clock generators, and communication interfaces where precise frequency control is required. The part is listed as RoHS compliant and REACH unaffected, but these compliance statuses are unverified and based on database entries with low confidence.
12 MHz.
18 pF.
4-SMD, No Lead.
-20°C to +70°C.
±30 ppm.
100 Ω.
It is listed as RoHS3 compliant, but this status is unverified.
