| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
150 pcs
|
150 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Contact Mating Finish | |
| Current | |
| Header Orientation | |
| Lead Spacing | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Positions Per Level | |
| Tape & Reel | |
| Termination Style | |
| Type | |
| Voltage |
The 796695-5 is a 5 position, single level terminal block header manufactured by TE Connectivity. It features a 3.50mm pitch and a 90 degree right angle orientation, making it suitable for compact PCB layouts where wire entry is perpendicular to the board. The header is shrouded on four sides, providing physical protection and polarization for mating plug connectors.
Electrical ratings include 300V voltage and 11A current per position. The contact mating finish is tin, offering good solderability and corrosion resistance. The operating temperature range is -40°C to 110°C, allowing use in a variety of industrial and commercial environments.
Mechanically, the header uses through hole mounting with solder termination for reliable PCB attachment. The housing is blue in color, which is a common identifier for TE Connectivity's terminal block product line. This component is RoHS3 compliant and REACH unaffected, with an MSL of 1 (unlimited floor life).
| Qty | Low | High |
|---|---|---|
| 1+ | $3.86 | $3.86 |
| 10+ | $2.75 | $2.75 |
| 25+ | $2.40 | $2.40 |
| 50+ | $2.19 | $2.19 |
| 100+ | $2.00 | $2.00 |
| 300+ | $1.82 | $1.82 |
| 600+ | $1.71 | $1.71 |
| 1,050+ | $1.62 | $1.62 |
| 5,100+ | $1.58 | $1.58 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
5 positions in a single level.
3.50mm (0.138 inches).
300V and 11A.
Through hole with solder termination.
-40°C to 110°C.
Tin.
