| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,400 pcs
|
5400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Current | |
| Current Rating | |
| Failure Rate | |
| Features | |
| Lead Spacing | |
| Mating Orientation | |
| Mounting Type | |
| Number of Levels | |
| Pitch | |
| Positions Per Level | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge | |
| Wire Termination |
The TE Connectivity 2-796683-2 is a 22-position wire to board terminal block from the Buchanan series. It features a 5.00mm pitch and through hole mounting, with a horizontal mating orientation relative to the board. The wire termination uses a screw rising cage clamp mechanism, accommodating wire gauges from 12 to 30 AWG. This terminal block is rated for 17.5A current and 300V voltage. It includes side interlocking features for secure stacking. The terminal block is colored green. It is suitable for industrial and commercial applications requiring reliable wire-to-board connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.87 | $1.87 |
| 10+ | $1.35 | $1.35 |
| 25+ | $1.18 | $1.18 |
| 50+ | $1.07 | $1.07 |
| 100+ | $0.97 | $0.97 |
| 300+ | $0.85 | $0.85 |
| 600+ | $0.80 | $0.80 |
| 1,200+ | $0.75 | $0.75 |
| 5,100+ | $0.69 | $0.69 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
22 positions per level.
5.00 mm (0.197 in).
17.5 A.
300 V.
Through hole.
12-30 AWG.
Screw - Rising Cage Clamp.
