| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,800 pcs
|
1800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
238 pcs
|
238 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request | |
|
23 pcs
|
23 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Color | |
| Connector System | |
| Contact Base Material | |
| Contact Mating Finish | |
| Current | |
| Current Rating (Max) | |
| Features | |
| Housing Color | |
| Housing Material | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Number of Levels | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Pitch | |
| Plug Wire Entry | |
| Positions Per Level | |
| SVHC Present | |
| Screw Size | |
| Termination Style | |
| Type | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge or Range |
The TE Connectivity 796634-2 is a 22-position wire-to-board terminal block plug with a 5.08mm pitch. This side-entry plug is designed for reliable power and signal connections in industrial and commercial applications. It features a right-angle through-hole mounting configuration and a green PA 66 housing.
Rated for 15A at 300VAC, the plug accepts wire sizes from 0.05 to 3 mm² (30-12 AWG). Contacts are phosphor bronze with tin plating, and screw terminals are brass with nickel plating. The stacking plug design allows side stacking for multi-level configurations.
Packaged in boxes of 25 units, this terminal block plug operates over a temperature range of -40°C to 105°C. It is compliant with RoHS and REACH, with low halogen content. The part is suitable for PCB terminal block applications requiring high-density wiring with secure screw connections.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.66 | $1.66 |
| 10+ | $1.36 | $1.36 |
| 25+ | $1.13 | $1.13 |
| 50+ | $1.07 | $1.07 |
| 100+ | $1.01 | $1.01 |
| 300+ | $0.90 | $0.90 |
| 600+ | $0.80 | $0.80 |
| 1,200+ | $0.60 | $0.60 |
| 5,100+ | $0.59 | $0.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
22 positions.
5.08 mm (0.2 inches).
Rated for 15 A maximum and 300 VAC.
Right angle through-hole mounting.
Wire sizes from 0.05 to 3 mm² (approximately 30 to 12 AWG).
-40°C to 105°C.
Yes, it has a side stackable configuration and supports stacked levels.
