| Category | |
| Manufacturer Name | |
| Maximum Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Type | |
| Output Voltage | |
| Voltage Dropout (Max) |
The Unisonic 78R05G-TN3-R is a linear voltage regulator designed to provide a stable 5V output. With a maximum output current of 1A, it is suitable for various power management applications. This component operates within a temperature range of -40°C to 85°C and has a maximum input voltage of 12V.
The regulator is housed in a TO-252 (DPAK) surface-mount package, facilitating integration into compact electronic designs. Its fixed output type ensures a consistent voltage supply for downstream circuitry. The device offers a power supply rejection ratio (PSRR) of 55 dB, contributing to cleaner power delivery.
Key electrical characteristics include a dropout voltage of 700mV at 1A. The 78R05G-TN3-R is designed for applications requiring a reliable and straightforward voltage regulation solution. Its specifications make it a practical choice for embedded systems and general-purpose power supply needs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.30 | $0.30 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 5V.
The maximum output current is 1A.
It is available in a TO-252-2 (DPAK) package.
The operating temperature range is -40°C to 85°C.
The maximum input voltage is 12V.
The dropout voltage is 700mV at 1A.
