| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
540 pcs
|
540 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Actuator Level | |
| Actuator Type | |
| Circuit | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| Features | |
| Height Above Board | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature | |
| Pitch | |
| Termination Style | |
| Voltage Rating | |
| Washable |
The Grayhill 78G01ST is a Thru-Hole DIP Switch designed for reliable operation in various applications. This switch features a 3PST (3 Pole Single Throw) circuit configuration with a single position, operated by a raised slide actuator.
Key electrical specifications include a current rating of 50mA at 30VDC. The contact material is copper alloy with a gold contact finish, ensuring good conductivity. The switch is designed for through-hole mounting with a PC pin termination style and has a pitch of 2.54mm (0.100").
Environmental and mechanical considerations include an operating temperature range of -40°C to 85°C and a mechanical life rating of 2,000 cycles. The tape seal feature enhances its suitability for processes requiring protection. It is also noted as washable.
This RoHS3 compliant component is suitable for applications requiring a compact and durable DIP switch solution. Its through-hole mounting makes it easy to integrate into PCB designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Grayhill 78G01ST DIP Switch has a current rating of 50mA at 30VDC.
The 78G01ST DIP Switch features a raised slide actuator.
The 78G01ST DIP Switch is designed for through-hole mounting.
The operating temperature range for the 78G01ST DIP Switch is -40°C to 85°C.
The 78G01ST DIP Switch has a mechanical life rating of 2,000 cycles.
Yes, the 78G01ST DIP Switch is RoHS3 Compliant.
