| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
30 pcs
|
30 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coating | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Dielectric Strength | |
| Frequency | |
| Inductance | |
| Lead Style | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Freq | |
| Shielding | |
| Standard Package Quantity | |
| Tape & Reel | |
| Temperature Rise | |
| Terminal Finish | |
| Tolerance | |
| Type | |
| Wire Type |
The Bourns 78F101J-RC is a 100 µH wirewound fixed inductor from the 78F series. It is designed for general purpose use in DC/DC converters, power supplies, and RF circuits. The inductor features a ferrite drum core with an unshielded construction and conformal epoxy coating.
Key electrical specifications include an inductance of 100 µH with ±5% tolerance, a minimum Q factor of 60 at 2.5 MHz, a self-resonant frequency of 5.5 MHz minimum, and a maximum DC resistance of 4.1 Ohm. The rated current is 165 mA with a temperature rise of 35°C at rated current.
The component is packaged in an axial through-hole configuration with dimensions of 0.110 inch diameter by 0.280 inch length (2.79 mm x 7.11 mm). It has a copper/tin terminal finish and an epoxy resin coating. The operating temperature range is -55°C to 105°C.
The inductor is RoHS compliant and has a moisture sensitivity level of 1 (unlimited). It is also REACH unaffected.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.19 | $0.19 |
| 10+ | $0.16 | $0.16 |
| 25+ | $0.15 | $0.15 |
| 100+ | $0.14 | $0.14 |
| 250+ | $0.13 | $0.13 |
| 1,000+ | $0.12 | $0.12 |
| 2,500+ | $0.11 | $0.11 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
100 µH with ±5% tolerance.
165 mA maximum.
4.1 Ohm maximum.
5.5 MHz minimum.
Axial through-hole package, dimensions 0.110 inch diameter x 0.280 inch length (2.79 mm x 7.11 mm).
60 at 2.5 MHz.
-55°C to 105°C.
