78D05AL-TN3-R The UTC 78D05AL-TN3-R is a linear voltage regulator designed for 5V output. It features a 1A output current capability and is housed in a TO-220-3 package for through-hole mounting.
Mfr Part #:

78D05AL-TN3-R

Available from 1 distributors
Mfr Name: UCT
UCT
The UTC 78D05AL-TN3-R is a linear voltage regulator designed for 5V output. It features a 1A output current capability and is housed in a TO-220-3 package for through-hole mounting.
✓ Total Stock: 3,466 pcs
$ Price Range: $0.08

78D05AL-TN3-R Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
3,466 pcs
On Request
3466 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

78D05AL-TN3-R Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Operating Temperature
Output Current
Output Voltage
SVHC Present
View Similar Products (0)

78D05AL-TN3-R Description

Short technical summary and product information.

The 78D05AL-TN3-R from UTC is a linear voltage regulator IC. It provides a stable 5V output voltage with a maximum output current of 1A. This component is suitable for applications requiring a regulated power supply.



The regulator has a maximum input voltage rating of 35V and a typical dropout voltage of 2V at 1A. It operates within a temperature range of -40°C to 125°C. The device is packaged in a TO-220-3 configuration, designed for through-hole mounting on a PCB.



This voltage regulator is a reliable choice for power management in various electronic circuits. Its through-hole design facilitates easy integration into existing or new designs.

78D05AL-TN3-R Quick Information

Product Type: Linear Voltage Regulator
Canonical Name: 78D05AL-TN3-R Linear Voltage Regulator
Subcategory: Linear

78D05AL-TN3-R Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

78D05AL-TN3-R Estimated Pricing

Qty Low High
1+ $0.08 $0.08

Estimated market price range - modelled values for guidance only, not live distributor offers.

78D05AL-TN3-R Features

  • Fixed 5V output voltage.
  • 1A maximum output current.
  • Wide input voltage range up to 35V.
  • Low dropout voltage of 2V at 1A.
  • Operating temperature range -40°C to 125°C.

78D05AL-TN3-R Applications

  • General-purpose 5V power supply regulation.
  • Microcontroller and digital circuit power rails.
  • Industrial control system power conditioning.
  • Battery-powered equipment voltage stabilization.

78D05AL-TN3-R FAQs

7 frequently asked questions generated from this part’s specifications.
What is the output voltage of the 78D05AL-TN3-R?

5V.

What is the maximum output current?

1A.

What is the maximum input voltage?

35V.

What is the dropout voltage?

2V typical at 1A output current.

What is the operating temperature range?

-40°C to 125°C.

What package does the 78D05AL-TN3-R come in?

TO-220-3.

What is the mounting type?

Through Hole.
