| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Backset Spacing | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Halogen Free | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| SVHC Present | |
| Shell Material | |
| Shell Material, Finish | |
| Shell Size | |
| Shell Size, Connector Layout | |
| Termination |
The TE Connectivity 787678-1 is a D-Sub stacked receptacle connector designed for board edge, through-hole, right angle mounting. It features two rows of 68 positions each (68+68 total) with female socket contacts. The connector is rated for 1A nominal current and has gold-plated contacts with a thickness of 30.0µin (0.76µm). The shell is made of steel with tin plating, and the flange includes housing/shell (2-56) and latchblocks/rails. A board lock feature is included for secure attachment. The connector is not RoHS compliant due to the presence of lead (Pb) and is not lead-free process capable. The material flammability rating is UL94 V-0.
The current rating is 1A nominal.
It has 68 positions in each of two rows, for a total of 68+68 positions.
The mounting type is board edge, through hole, right angle.
No, it is not RoHS compliant due to the presence of lead (Pb).
The contact finish is gold with a thickness of 30.0µin (0.76µm).
