This electronic circuit breaker from Wago Corporation, model 787-1662/000-054, offers a space-saving solution with two independent channels. Each channel operates with a nominal input voltage of 24 VDC and can be individually adjusted for nominal output current between 2 A and 10 A using a sealable selector switch, with a factory preset of 2 A.
The device supports a wide input voltage range of 18 to 30 VDC and provides an output voltage range of 18 to 30 VDC with a maximum voltage drop of 200 mV. It features time-delayed channel switching, with trip times ranging from 16 ms to 100 s depending on the load. The switch-on capacity is rated at over 50,000 µF per channel, and it supports time-delayed channel switching between 50 ms and 5 s.
Signaling is provided via two LEDs per channel (green/red/orange) and a common group signal contact. A remote input allows for reactivation of all tripped channels. The circuit breaker is designed for DIN rail mounting and utilizes Push-in CAGE CLAMP® technology for input connections and CAGE CLAMP® for output and signaling connections. It has an IP20 protection rating and an MTBF of over 500,000 hours.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal input voltage is 24 VDC, with an operating range of 18 to 30 VDC.
Each channel's nominal output current is adjustable from 2 A to 10 A.
The switch-on capacity is greater than 50,000 µF per channel.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level is 1.
