| Category | |
| Manufacturer Name | |
| ET (Volt | |
| Height | |
| Inductance | |
| Length | |
| Mounting Type | |
| Operating Temperature | |
| Storage Temperature | |
| Tape & Reel | |
| Transformer Type | |
| Turns Ratio | |
| Width |
The Murata 78613/16C is a general purpose pulse transformer designed for various electronic applications. It features an inductance of 4mH and a turns ratio of 1CT:1, with an ET product rating of 28VµS.
This transformer is suitable for operation within a temperature range of 0°C to 70°C. Its mechanical dimensions include a length of 9.52mm (0.375"), a width of 9.00mm (0.354"), and a seated height of 6.35mm (0.250"). The through-hole mounting type ensures secure installation on printed circuit boards.
Packaged in a tube, the 78613/16C is identified by its manufacturer part number 78613/16C and belongs to the 786 series. It is classified under the Pulse Transformers category, offering a reliable solution for signal conditioning and power transfer needs.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.00 | $3.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 4mH.
The turns ratio is 1CT:1.
The operating temperature range is 0°C to 70°C.
It is a through-hole mounted component.
The dimensions are 9.52mm L x 9.00mm W x 6.35mm H.
