| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
300 pcs
|
300 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination |
The 77315-802-36LF is a 36-position unshrouded breakaway header from Amphenol ICC. It has a single row of male square pins with a 2.54mm (0.100") pitch. The contacts are made of phosphor bronze with a tin finish (15.0µin thickness). The header is designed for through hole right angle mounting with solder termination. The insulation is black thermoplastic with a UL94 V-0 flammability rating. The insulation height is 2.40mm (0.094") and the contact length is 5.72mm (0.225"). The operating temperature range is -65°C to 125°C. This header is suitable for board-to-board applications where a low-profile right-angle connection is required. The breakaway feature allows the connector to be snapped to the desired number of positions.
36 positions, single row, all positions loaded.
2.54mm (0.100 inch).
3A per contact.
Through hole, right angle.
-65°C to 125°C.
Phosphor bronze contacts with tin finish, 15.0µin (0.38µm) thickness.
Black thermoplastic insulation with UL94 V-0 flammability rating.
