| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
600 pcs
|
600 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination |
The 77315-424-16LF is a 16-position unshrouded breakaway header from Amphenol ICC. It features a single row of male pins with a 2.54mm pitch, designed for through hole right angle mounting via solder termination. The contact material is phosphor bronze with a tin finish of 78.7µin thickness, providing reliable conductivity and corrosion resistance.
This header is rated for 3A per contact and operates across a temperature range of -65°C to 125°C. The insulation is made of black thermoplastic with a UL94 V-0 flammability rating, and the housing height is 2.40mm. With a push-pull fastening type and unshrouded design, it is suitable for board-to-board connections where low profile and secure mating are required.
The component is RoHS compliant and REACH unaffected, though compliance status is unverified. It is commonly used in industrial controls, telecommunications, and consumer electronics for prototyping or production PCBs.
| Qty | Low | High |
|---|---|---|
| 15+ | $5.20 | $5.20 |
| 75+ | $5.10 | $5.10 |
| 150+ | $5.00 | $5.00 |
| 300+ | $4.90 | $4.90 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
16 positions in a single row.
2.54mm (0.100 inches).
3A per contact.
Through hole, right angle.
Tin with a thickness of 78.7µin (2.00µm).
-65°C to 125°C.
Black thermoplastic with UL94 V-0 rating.
