| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
300 pcs
|
300 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The Amphenol ICC 77313-418-72LF is a 72-position, dual-row, through-hole male pin header with a 2.54mm pitch and row spacing. Part of the unshrouded breakaway header family, it supports board-to-board or cable connections.
Each of the 72 square pins is made of phosphor bronze with a 2.0µm tin finish. The header is rated for 3A per contact and operates over -65°C to 130°C. The black thermoplastic insulator is UL94 V-0 rated.
The push-pull fastening type and solder termination make it suitable for prototyping and production. The 5.84mm contact length and 11.43mm overall contact length provide reliable mating.
Through-hole mounting with solder termination. The insulation height is 2.54mm. All 72 positions are loaded.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.93 | $2.93 |
| 10+ | $2.49 | $2.49 |
| 100+ | $2.12 | $2.12 |
| 500+ | $1.89 | $1.89 |
| 1,000+ | $1.80 | $1.80 |
| 5,000+ | $1.61 | $1.61 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
72 positions.
2.54mm (0.100 inches).
3A per contact.
-65°C to 130°C.
Through hole with solder termination.
Phosphor bronze with a 2.0µm tin finish.
