| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
500 pcs
|
500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Length - Mating | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The 77313-124-14LF is a 14-position, 2-row, 2.54mm pitch through-hole header from Amphenol ICC. It features unshrouded male pins with square contacts made of phosphor bronze, plated with 30µin tin. The insulation is black thermoplastic rated UL94 V-0, with a height of 2.54mm. The overall contact length is 0.480" (12.19mm) with a mating length of 6.75mm.
This header is designed for board-to-board or cable connections with a push-pull fastening type. It is rated for 3A per contact and operates over a temperature range of -65°C to 130°C. The through-hole mounting with solder termination ensures reliable mechanical and electrical connections.
Typical applications include general-purpose interconnection in industrial, consumer, and telecommunications equipment. The 2.54mm pitch is compatible with standard breadboards and prototyping systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.05 | $1.05 |
| 10+ | $0.89 | $0.89 |
| 100+ | $0.76 | $0.76 |
| 500+ | $0.68 | $0.68 |
| 1,000+ | $0.64 | $0.64 |
| 5,000+ | $0.57 | $0.57 |
| 10,000+ | $0.55 | $0.55 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
14 positions.
2.54mm (0.100").
3A per contact.
Through hole.
2 rows.
Tin with 30µin (0.76µm) thickness.
-65°C to 130°C.
