| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,500 pcs
|
1500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The Amphenol ICC 77313-101-14LF is a 14-position, unshrouded header connector with male pins arranged in two rows at a 2.54mm pitch. It is designed for through-hole mounting and uses solder termination, making it suitable for board-to-board or cable connections. The header is constructed with a black thermoplastic insulator rated UL94 V-0, and phosphor bronze contacts with a tin finish (30µin thickness). Each contact is rated for 3A current. The overall contact length is 0.425" (10.80mm), with a contact length of 0.230" (5.84mm) and insulation height of 0.100" (2.54mm). Operating temperature range is -65°C to 130°C. This breakaway header allows for easy customization of pin count.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.87 | $0.87 |
| 10+ | $0.74 | $0.74 |
| 100+ | $0.63 | $0.63 |
| 500+ | $0.56 | $0.56 |
| 1,000+ | $0.54 | $0.54 |
| 5,000+ | $0.48 | $0.48 |
| 10,000+ | $0.46 | $0.46 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
14 positions arranged in 2 rows.
2.54mm (0.100").
3A per contact.
Through hole mounting with solder termination.
-65°C to 130°C.
