| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
187 pcs
|
187 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
13 pcs
|
13 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Current Rating (Amps) | |
| Lead Style | |
| Mounting Type | |
| Number of Pins | |
| Number of Positions | |
| Screw Length | |
| Screw Material | |
| Screw Size | |
| Screw Supplied | |
| Terminal Material | |
| Terminal Type | |
| Termination | |
| Termination Style | |
| Wire Range (AWG) |
The Keystone Electronics 7690 is a 4-position screw terminal connector designed for through hole, right angle mounting with snap-fit legs. It is rated for 15A continuous current and accommodates 14-22 AWG solid or stranded wire, crimp terminals, or lugs. The terminal is made of 0.032" brass with matte tin plate, and the binding head screw is brass with nickel plate, size 6-32 x 0.250" long, supplied unassembled. The low-profile design includes an anti-rotational feature for stable mounting and is suitable for high-density PCB packaging. This terminal is a practical, low-cost alternative to barrier blocks, terminal strips, and PC screw-type edge connectors. It mounts easily into pre-drilled or punched holes using four legs.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.57 | $0.57 |
| 10+ | $0.50 | $0.50 |
| 1,000+ | $0.31 | $0.31 |
| 2,500+ | $0.28 | $0.28 |
| 5,000+ | $0.24 | $0.24 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
4 positions.
15A.
Through hole, right angle with snap-fit.
14-22 AWG solid or stranded wire.
6-32.
Unassembled.
Terminal: brass with matte tin plate; screw: brass with nickel plate.
