Mfr Part #:

769-603/002-000

Wago 769-603/002-000 is a 3-position male connector (plug) with 5.00mm pitch, featuring CAGE CLAMP push-in spring termination. It is rated for 500V and 32A, accepts 0.08-4mm² wire, and is suitable for free hanging (in-line) mounting.

✓ Total Stock: 24 pcs

$ Price Range: $5.83 - $12.68

769-603/002-000 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Tomark Electronics Ltd ✓ Non-Authorised Inventory information	24 pcs On Request	24 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

769-603/002-000 Description

Short technical summary and product information.

The Wago 769-603/002-000 is a 3-pole male connector from the 769 Series, designed for use in pluggable terminal block systems. It features CAGE CLAMP push-in spring connection technology, allowing tool-less termination of solid and fine-stranded copper conductors from 0.08 mm² to 4 mm² (28-12 AWG). The connector has a pin spacing of 5.00 mm and is rated for 500 V (overvoltage category III/3) and 32 A. It is suitable for free hanging (in-line) mounting and includes a mounting flange for secure panel mounting. The housing is made of gray polyamide (PA66) with a flammability class of V0. The operating temperature range is -60°C to +105°C. This male connector is ideal for use in switchgear, control systems, and railroad technology, where reliable and maintenance-free connections are required. The push-in spring termination reduces installation time and does not require ferrule preparation. The connector is supplied in a box of 50 pieces.

769-603/002-000 Quick Information

Product Type: Male Connector (Plug)

Series: 769

Canonical Name: Wago 769-603/002-000 3-Pole Male Connector, 5mm Pitch, CAGE CLAMP, 4mm², Gray

Subcategory: Pluggable Terminal Block Plug

769-603/002-000 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

769-603/002-000 Estimated Pricing

Qty	Low	High
1+	$12.68	$12.68
10+	$9.01	$9.01
25+	$7.98	$7.98
50+	$7.36	$7.36
100+	$6.86	$6.86
250+	$6.35	$6.35
500+	$6.06	$6.06
1,000+	$5.83	$5.83

Estimated market price range - modelled values for guidance only, not live distributor offers.

769-603/002-000 Features

3-pole male connector with 5.00mm pitch.
CAGE CLAMP push-in spring termination.
Rated for 500V and 32A.
Accepts 0.08-4mm² copper conductors.
Free hanging mounting with mounting flange.

769-603/002-000 Applications

Ideal for switchgear and control systems.
Used in railroad technology applications.
Suitable for through-panel wiring.
Pre-assembly in variable wiring systems.

769-603/002-000 FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the Wago 769-603/002-000 have?

3 positions.

What is the pitch of this connector?

5.00 mm (0.197 inches).

What is the current rating?

32 A.

What is the voltage rating?

500 V (overvoltage category III/3).

What is the mounting type?

Free hanging (in-line) with mounting flange.

What termination style does it use?

Screwless - Push-In Spring (CAGE CLAMP).

What wire sizes are compatible?

Solid and fine-stranded copper conductors from 0.08 mm² to 4 mm² (28-12 AWG).

Category	Headers, Plugs and Sockets
Manufacturer Name	Wago Corporation
AEC Qualified	No
Automotive Grade	No
Color	Gray
Current	32A
Depth	40.2 mm / 1.583 inches
Features	Mounting Flange
Industrial Grade	Yes
Insulation Material	Polyamide (PA66)
Lead Spacing	5.0 mm
Lead Style	Screwless - Push-In Spring
Medical Grade	No
Military Grade	No
Mounting Type	Free Hanging (In-Line)
Number of Levels	1
Number of Positions	3
Pitch	5.00mm (0.197")
Plug Wire Entry	180°
Positions Per Level	3
SVHC Present	Not Present
Termination Style	Screwless - Push-In Spring
Type	Plug, Male Pins
Voltage	500 V
Weight	10.7 g
Width	30.4 mm / 1.197 inches
Wire Gauge or Range	0.08-4mm²
