769-127 Wago 769-127 is a 2-conductor female connector with 7 positions, 5 mm pitch, and CAGE CLAMP termination. Rated 32 A and 500 V.
Mfr Part #:

769-127

Available from 1 distributors
Mfr Name: Wago Corporation
Wago Corporation
Wago 769-127 is a 2-conductor female connector with 7 positions, 5 mm pitch, and CAGE CLAMP termination. Rated 32 A and 500 V.
✓ Total Stock: 10 pcs
$ Price Range: $30.62

769-127 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

769-127 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Color
Conductor Material
Current
Current Rating
Depth
Failure Rate
Features
Height
Lead Spacing
Lead Style
Mounting Type
Number of Levels
Number of Positions
Pitch
Plug Wire Entry
Positions Per Level
Termination Style
Type
Voltage
Voltage Rating
Width
Wire Gauge or Range
View Similar Products (0)

769-127 Description

Short technical summary and product information.

The Wago 769-127 is a 2-conductor female connector from the 769 series, designed for pluggable rail-mount terminal block applications. It features 7 positions with a 5 mm pitch and uses CAGE CLAMP connection technology for tool-free, maintenance-free wiring of solid and fine-stranded copper conductors from 0.08 to 4 mm² (28 to 12 AWG).



The connector is rated for 32 A and 500 V per IEC/EN 61984, with an overvoltage category III and pollution degree 3. It has a front-entry wiring direction with a 180° plug wire entry and is actuated using an operating tool. The housing is gray and includes retention latches on the non-wire side.



Dimensions are 35 mm width, 45.2 mm height, and 35.9 mm depth. The connector is free hanging (in-line) and requires a strip length of 8 to 9 mm. Variable coding allows for mechanical keying to prevent mismating.

769-127 Quick Information

Product Type: Female Connector / Socket
Series: 769
Canonical Name: Wago 769-127 2-Conductor Female Connector, CAGE CLAMP, 7 Pole, 5 mm Pitch
Subcategory: Female Socket

769-127 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

769-127 Estimated Pricing

Qty Low High
1+ $30.62 $30.62

Estimated market price range - modelled values for guidance only, not live distributor offers.

769-127 Features

  • 7 positions with 5 mm pitch.
  • CAGE CLAMP push-in spring termination.
  • Rated 32 A and 500 V.
  • Accepts 0.08 to 4 mm² wire.
  • Free hanging in-line mounting.

769-127 Applications

  • Used in switchgear and control systems.
  • Suitable for railway technology applications.
  • Ideal for pre-assembled installations.
  • For pluggable rail-mount terminal blocks.

769-127 FAQs

6 frequently asked questions generated from this part’s specifications.
How many positions does the Wago 769-127 have?

The connector has 7 positions on the mate side and 14 positions on the input side.

What is the pitch of the Wago 769-127?

The pitch is 5.00 mm.

What is the current and voltage rating?

Rated 32 A and 500 V per IEC/EN 61984.

What wire sizes does the 769-127 accept?

Accepts 0.08 to 4 mm² (28 to 12 AWG) copper conductors.

What termination technology does it use?

CAGE CLAMP push-in spring connection, no tool preparation needed.

What is the mounting type?

Free hanging (in-line) mounting.
