767054-6

The TE Connectivity 767054-6 is a 228-position receptacle connector featuring center strip contacts arranged in two rows with a fine 0.64mm pitch. Designed for surface mount assembly, this connector provides a compact board-to-board interconnect solution for applications requiring high-density signal routing. The connector supports multiple mated stacking heights ranging from 6.6mm to 22.86mm, offering design flexibility across different board spacing requirements.\n\nThe contacts are plated with a 5 microinch palladium-nickel finish, providing reliable electrical performance and durability. The connector includes a board guide and an integrated ground bus plane, aiding alignment during assembly and improving signal integrity. The height above board is 0.236 inches (6.00mm), and the component is housed in a package suitable for automated pick-and-place processes.\n\nThis connector is classified as part of the Arrays, Edge Type, Mezzanine (Board to Board) category, making it suitable for mezzanine card or parallel board stacking configurations. Its high pin count and fine pitch make it appropriate for dense interconnect applications in telecommunications, computing, or industrial equipment.\n\nThe product is RoHS3 compliant and REACH unaffected, though compliance status is unverified as no certification documents are currently available. The standard package quantity and tape/reel details are not provided. No lead time or pricing data is available.
