| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | 00+22 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Height Above Board | |
| Lead Spacing | |
| Lead Style | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Tape & Reel |
The TE Connectivity 767054-2 is a mezzanine (board-to-board) receptacle connector featuring 76 positions arranged in 2 rows with a 0.64mm pitch. The connector uses a center strip contact design and is surface mount mounted.
Key mechanical specifications include a height above board of 6.00mm (0.236") and support for mated stacking heights ranging from 6.6mm to 22.86mm, offering flexible board spacing. The contacts are finished with palladium-nickel to a thickness of 5.00µin (0.127µm).
The connector includes a board guide and ground bus (plane) feature for alignment and grounding. The palladium-nickel contact finish provides durability and corrosion resistance in repeated mating cycles.
| Qty | Low | High |
|---|---|---|
| 14+ | $56.35 | $56.35 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
76 positions arranged in 2 rows.
0.64mm (0.025").
Surface mount (SMT).
Palladium-nickel with a thickness of 5.00µin (0.127µm).
6.6mm, 9mm, 10.92mm, 12.57mm, 17.96mm, 18.75mm, 20mm, and 22.86mm.
Yes, it includes a board guide and a ground bus (plane).
