| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,000 pcs
|
1000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style |
The Amphenol ICC 76385-303LF is a 6-position, 2-row shrouded header designed for board-to-cable/wire applications. It features a 2.54mm (0.100") pitch and row spacing, with through hole solder termination. The contacts are made of copper alloy with a tin finish (0.76µm thickness) and have a square shape. The overall contact length is 10.44mm (0.411"), with a contact length of 5.00mm (0.197").
The insulator is molded from black thermoplastic, glass-filled material with a UL94 V-0 flammability rating. The shrouding is of the 2-wall type, and the fastening mechanism is a friction lock to prevent accidental disconnection. The header is rated for a current of 3A and an operating temperature range of -40°C to 125°C.
This component is suitable for a variety of wire-to-board interconnection needs where a secure, reliable connection is required. The through hole mounting provides robust mechanical attachment to the PCB. The part is listed as RoHS3 compliant, REACH unaffected, and has an MSL of Level 1 (unlimited).
| Qty | Low | High |
|---|---|---|
| 1+ | $1.08 | $1.08 |
| 10+ | $0.92 | $0.92 |
| 100+ | $0.78 | $0.78 |
| 500+ | $0.70 | $0.70 |
| 1,000+ | $0.66 | $0.66 |
| 5,000+ | $0.59 | $0.59 |
| 10,000+ | $0.57 | $0.57 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 6 positions, all loaded.
The pitch is 2.54mm (0.100").
The current rating is 3A.
Through hole mounting with solder termination.
-40°C to 125°C.
Tin finish with a thickness of 0.76µm (30.0µin).
Friction lock.
