The Amphenol ICC 76383-303LF is a 6-position, 2.54mm pitch header connector designed for board-to-cable/wire interconnections. It features a right-angle through-hole mounting style, allowing efficient PCB layouts where space is constrained.
The connector offers a shrouded 2-wall design with a friction lock mechanism, ensuring secure mating and reliable retention. The contacts are made of phosphor bronze with a 30µin tin finish, providing good conductivity and corrosion resistance. The insulation is blue glass-filled polyester with a UL94 V-0 flammability rating.
Electrically, the header is rated for a current of 3A and operates over a temperature range of -40°C to 125°C. The 2.54mm pitch and row spacing are standard for many applications. The fastening type is friction lock, suitable for applications requiring a secure connection without additional hardware.
Mounting is through-hole, right-angle with solder termination. The part is unverified RoHS3 compliant. Standard packaging quantity is not specified. The part is also known under DigiKey part number 609-1365-ND.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.93 | $0.93 |
| 10+ | $0.79 | $0.79 |
| 100+ | $0.67 | $0.67 |
| 500+ | $0.60 | $0.60 |
| 1,000+ | $0.57 | $0.57 |
| 5,000+ | $0.51 | $0.51 |
| 10,000+ | $0.49 | $0.49 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions.
2.54mm (0.100").
3A.
Through Hole, Right Angle.
-40°C to 125°C.
Friction Lock.
Tin, 30.0µin thickness.
