| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Type | |
| Insulation Resistance | |
| Length | |
| Operating Temperature | |
| Output Connector | |
| Power (Watts) | |
| Storage Temperature | |
| Temperature Coefficient | |
| Tolerance | |
| Voltage | |
| Width |
This AC/DC desktop adapter, part number 76000904 from Digi, delivers a stable 18V output with a maximum load current of 1A, providing a total continuous power of 18 watts.
Designed for versatility, it accepts a universal AC input voltage range from 90VAC to 254VAC and operates within a frequency range of 47Hz to 63Hz. The adapter boasts an efficiency of 78% minimum at maximum load and 220VAC input. It includes essential protections such as short circuit protection and operates reliably within an environmental temperature range of -40°C to 75°C.
The unit is housed in a desktop (Class I) form factor and utilizes a 4-position rectangular output connector. Its dimensions are 150.0mm in length, 90.0mm in width, and 52.0mm in height. The input type is a cord, with a cord length of 48 inches (1.22m).
Safety and compliance are addressed with CE agency approval. The adapter also meets specific electrical characteristics like a maximum leakage current of 3.5 mA and a minimum hold-up time of 10ms at 120VAC.
The output voltage is 18V and the maximum load current is 1A.
The AC input voltage range is 90VAC to 254VAC.
The operating temperature range is -40°C to 75°C.
Yes, it has protection against short circuit for the output.
The minimum efficiency is 78% at max load and 220VAC.
The dimensions are 150.0mm (length) x 90.0mm (width) x 52.0mm (height).
