| Category | |
| Manufacturer Name | |
| Applications | |
| Cord Length | |
| Current | |
| Form | |
| Input Connector | |
| Input Frequency | |
| Input Type | |
| Input Voltage | |
| Operating Temperature | |
| Output Connector | |
| Output Power | |
| Output Voltage | |
| Power (Watts) | |
| Region Utilized | |
| Storage Temperature | |
| Voltage | |
| Weight |
This Digi AC/DC power adapter, part number 76000736, is designed for ITE (Commercial) applications. It delivers a stable 12VDC output with a maximum load current of 1.0A, providing a total output power of 12W.
The adapter accepts a wide input voltage range of 120VAC to 240VAC at 47Hz to 63Hz. The input connector is an IEC320 C14, and the output is provided via bare wire leads. It includes a 4 ft (1.22m) cord for convenient placement.
With an operating temperature range of -35°C to 74°C and a storage temperature range of -35°C to 85°C, this desktop adapter is built for demanding environments. Its compact dimensions are 93 x 34.3 x 57mm, and it weighs 220g.
The 76000736 accepts a 120-240 VAC input at 47-63 Hz.
The 76000736 operates from -35°C to 74°C.
The adapter provides 12 VDC at 1.0 A with a maximum power of 12 W.
It features an IEC320 C14 input connector.
The output is bare wires for direct wiring.
It is a desktop (Class I) adapter with an AC power cord.
It is designed for commercial ITE (Information Technology Equipment) applications.
