This Digi 76000696 is an enclosed DC to DC converter designed for ITE (Commercial) applications. It features a 12W continuous output power rating and delivers a stable +12V output voltage with a maximum load current of 1A. The converter operates efficiently with a minimum efficiency of 70% at maximum load.
The input voltage range for this unit is -36V to -72V DC, with a nominal rating of -48V DC. It includes essential protections such as over-voltage protection and short-circuit protection with automatic recovery. The operating temperature range is from 0°C to 40°C, and it has a Mean Time Between Failures (MTBF) of 100,000 hours minimum.
Physical dimensions are 74.0mm in length, 49.0mm in width, and 40.5mm in height. The converter meets safety requirements including UL 60950 and cUL/CSA 22.2, NO. 60950, and complies with CISPR EN55022 class B for EMI requirements.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is +12V.
The maximum output power is 12W continuous.
The DC input voltage range is -36V to -72V.
The operating temperature range is 0°C to 40°C.
Yes, it has protection against short circuits with automatic recovery.
