| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
200 pcs
|
200 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The Amphenol ICC 75869-132LF is a 8 position, 2 row, 2.54mm pitch through hole header with male pin contacts. It features a shrouded 4-wall design for improved mating alignment and protection. The connector uses a push-pull fastening type and includes a keying slot for polarization.
The contacts are made of phosphor bronze with a tin finish (30.0µin thickness). The insulator is blue thermoplastic, glass filled, rated UL94 V-0 for flammability. The insulation height is 9.57mm and the contact length is 6.00mm. This header is designed for board to cable/wire applications and is RoHS3 compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.04 | $1.04 |
| 10+ | $0.88 | $0.88 |
| 100+ | $0.75 | $0.75 |
| 500+ | $0.67 | $0.67 |
| 1,000+ | $0.64 | $0.64 |
| 5,000+ | $0.57 | $0.57 |
| 10,000+ | $0.54 | $0.54 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 positions, all loaded.
2.54mm (0.100") with a row spacing of 0.100" (2.54mm).
Through hole with solder termination.
Tin finish, 30.0µin (0.76µm) thickness, over phosphor bronze contact material.
Yes, it has a shrouded 4-wall design.
Thermoplastic, glass filled, rated UL94 V-0.
