| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
700 pcs
|
700 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | 2236 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination |
The Amphenol ICC 75867-132LF is a 8-position, 2-row rectangular header designed for board-to-cable/wire applications. It features a 2.54mm (0.100") pitch and a right-angle through-hole mounting style with solder termination. The connector is fully shrouded with a 4-wall design and includes a keying slot for polarization.
The header uses square male pin contacts made of phosphor bronze with a tin finish (30.0µin / 0.76µm). The insulation is blue thermoplastic, glass-filled, rated UL94 V-0 for flammability. The push-pull fastening type ensures secure mating. This component is suitable for applications requiring a reliable, polarized connection in a compact form factor.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.11 | $1.11 |
| 10+ | $0.95 | $0.95 |
| 100+ | $0.81 | $0.81 |
| 500+ | $0.72 | $0.72 |
| 1,000+ | $0.68 | $0.68 |
| 5,000+ | $0.61 | $0.61 |
| 10,000+ | $0.58 | $0.58 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 75867-132LF has 8 positions arranged in 2 rows.
The pitch is 2.54mm (0.100").
It is a through-hole, right angle mounting type with solder termination.
Yes, it features a shrouded 4-wall design with a keying slot.
Contacts are phosphor bronze with a tin finish of 30.0µin (0.76µm).
The insulation is blue thermoplastic, glass filled, with a UL94 V-0 flammability rating.
