| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
800 pcs
|
800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Storage Temperature | |
| Style | |
| Termination | |
| Voltage Rating |
The 75844-150-26LF is a 26-position breakaway header from Amphenol ICC, part of the 75844 series. It features a 2-row configuration with 2.54mm pitch and 2.54mm row spacing, making it suitable for high-density board-to-board or cable connections. The unsrouded, push-pull design allows for easy mating and unmating.
Electrical ratings include 5A current and 110V voltage, with an operating temperature range of -65°C to 130°C. Contacts are made of phosphor bronze with a gold GXT finish of 30µin (0.76µm) for reliable conductivity and corrosion resistance. The thermoplastic insulation material is rated UL94 V-0 for flammability.
This through hole header has an overall contact length of 0.453" (11.50mm) and a contact length of 0.230" (5.84mm). The insulation height is 2.54mm. It is designed for solder termination and is compatible with standard PCB layouts. The breakaway feature allows the header to be snapped to custom lengths if needed, though all positions are loaded.
26 positions.
2.54mm (0.100").
5A.
110V.
Through hole.
-65°C to 130°C.
Gold, GXT with 30µin thickness.
