| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
9,500 pcs
|
9500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The 75160-802-07LF is a 7-position single row male pin header manufactured by Amphenol ICC. This connector is part of the board-to-board style series and features a 2.54mm (0.100") pitch, making it suitable for standard spacing applications. The header is unshrouded with a push-pull fastening type, allowing for easy mating and unmating.
The contacts are made of phosphor bronze with a gold GXT™ finish of 15.0µin (0.38µm) thickness, providing excellent conductivity and corrosion resistance. The square contact shape ensures reliable electrical connections. The contact length is 5.84mm (0.230") and the overall contact length is 0.465" (11.81mm). The insulation height is 2.54mm (0.100").
Designed for through hole mounting with solder termination, this header is suitable for PCB assembly. The thermoplastic insulation material is rated UL94 V-0 for flammability, and the operating temperature ranges from -65°C to 130°C. Electrical ratings include 5A current and 110V voltage. The component is black in color and comes in a single row configuration.
| Qty | Low | High |
|---|---|---|
| 200+ | $0.42 | $0.42 |
| 500+ | $0.51 | $0.51 |
| 600+ | $0.39 | $0.39 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
7 positions.
2.54mm (0.100").
5A.
110V.
Through hole.
Gold, GXT™ with 15.0µin thickness.
-65°C to 130°C.
