| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
392 pcs
|
392 pcs | On Request | 1 | On Request | On Request | 07+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Latch-up Performance | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Tape & Reel | |
| Voltage |
The 74LVTH16245MTDX is a low-voltage 16-bit transceiver designed for bus-oriented applications. It features non-inverting, bidirectional buffers with 3-STATE outputs, allowing for flexible data flow control.
This transceiver operates at a VCC of 3.3V and is capable of providing a TTL interface to a 5V environment. The device is byte-controlled, with separate control inputs for each byte that can be tied together for full 16-bit operation. The OE inputs disable both A and B ports by placing them in a high impedance state.
Key electrical characteristics include an output current sourcing/sinking capability of 32mA/64mA and latch-up performance exceeding 500mA. It operates within a temperature range of -40°C to 85°C.
The 74LVTH16245MTDX is supplied in a 48-TSSOP surface-mount package and is compatible with the 74 series 16245. It is also available in tape and reel packaging.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating voltage is 3.3V.
It comes in a 48-TSSOP package.
-40°C to 85°C.
3200V Human Body Model, 320V Machine Model, and 1000V Charged Device Model.
The datasheet specifies 32mA maximum, while the manufacturer page lists 64mA maximum.
Exceeds 500mA.
