The 74LS273N is a TTL (Transistor-Transistor Logic) integrated circuit belonging to the 74xx series. It functions as an octal D-type flip-flop, meaning it contains eight individual D-type flip-flops within a single package. Each flip-flop has data inputs (D0-D7), a common clock input (CP), and a master reset input (MR) that is active-low.
The outputs (Q0-Q7) are triggered on the rising edge of the clock signal. The master reset function allows all flip-flops to be cleared to a low state simultaneously. This IC is commonly available in DIP (Dual In-line Package) and SOP (Small Outline Package) formats, with the DIP-20 package being prevalent in applications like arcade and pinball machines.
With a typical operating voltage of 5V, the 74LS273N is suitable for data storage, address decoding, and general-purpose sequential logic applications where multiple flip-flops are required. Its design makes it a versatile component for various digital logic circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $9.22 | $9.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 74LS273N is a D-type flip-flop.
The 74LS273N contains eight flip-flops.
The typical operating voltage for the 74LS273N is 5V.
The 74LS273N is available in DIP and SOP package types.
Yes, the 74LS273N includes an active-low Master Reset (MR) input for clearing all flip-flops.
The flip-flops in the 74LS273N are triggered on the rising edge of the clock signal.
