74HC123M The HAR 74HC123M is a dual retriggerable monostable multivibrator IC. It operates with a supply voltage range of 2V to 6V and has an operating temperature range of -40°C to 85°C.
Mfr Part #:

74HC123M

Available from 1 distributors
Mfr Name: HAR
HAR
The HAR 74HC123M is a dual retriggerable monostable multivibrator IC. It operates with a supply voltage range of 2V to 6V and has an operating temperature range of -40°C to 85°C.
✓ Total Stock: 768 pcs
$ Price Range: $2.01

74HC123M Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
768 pcs
On Request
768 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

74HC123M Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Operating Temperature
Output Current
Quiescent Current
Storage Temperature
Supply Voltage
Tape & Reel
View Similar Products (0)

74HC123M Description

Short technical summary and product information.

The 74HC123M from HAR is a versatile dual retriggerable monostable multivibrator integrated circuit. Each monostable multivibrator features direct (Q) and inverted (Q) outputs, a reset input (CLR) active at low level, and two trigger inputs: direct (B) and inverted (A).



The duration of the output pulse is determined by external R and C timing components, following the formula Tвых=R*C. The device allows for pulse extension by applying a new voltage transition to the trigger input while the output pulse is active. The output pulse can be terminated by applying a low-level voltage to the reset input.



Key electrical characteristics include a supply voltage range of 2V to 6V, a maximum output voltage low of 0.1V, and a minimum output voltage high of Uпит-0.1V. It offers a load capability of 10 TTL inputs and a maximum output current of 25mA for logic '0'. The quiescent current is a maximum of 80µA, with an input current of 1µA at logic levels 1/0.



Available in DIP-16 and SO-16 packages, the 74HC123M operates within a temperature range of -40°C to 85°C. This component is compatible with other standard CMOS logic ICs in terms of input and output signal levels.

74HC123M Quick Information

Product Type: Dual Retriggerable Monostable Multivibrator
Canonical Name: 74HC123M Dual Retriggerable Monostable Multivibrator
Subcategory: Dual Retriggerable

74HC123M Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

74HC123M Estimated Pricing

Qty Low High
1+ $2.01 $2.01

Estimated market price range - modelled values for guidance only, not live distributor offers.

74HC123M Features

  • Dual retriggerable monostable multivibrator.
  • Adjustable pulse duration via R/C.
  • Supply voltage from 2V to 6V.
  • Wide operating temperature range.
  • Available in DIP-16 and SO-16 packages.

74HC123M Applications

  • Pulse generation circuits.
  • Timing control applications.
  • Delay circuits.
  • Oscillator circuits.

74HC123M FAQs

5 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the 74HC123M?

The supply voltage range for the 74HC123M is 2V to 6V.

What is the operating temperature range of the 74HC123M?

The operating temperature range of the 74HC123M is -40°C to 85°C.

What packages is the 74HC123M available in?

The 74HC123M is available in DIP-16 and SO-16 packages.

What is the maximum output current for the 74HC123M?

The maximum output current for the 74HC123M when outputting logic '0' is 25mA.

What is the quiescent current of the 74HC123M?

The maximum quiescent current of the 74HC123M is 80µA.
